LMD17/PM42 Electronique Integree IP20 *12-48V/*0051
SKU
577476
Integral axis motion controller positioning motor with 1000-point encoder - Configurable I/O - Standalone operation via memorised cycle - no-step losses integrated - Torque Mode. See instructions. 4-Year warranty
5 days up to 5 units.
- Buy 2 for €783.00 each and save 9%
- Buy 5 for €738.00 each and save 14%
- Buy 10 for €647.00 each and save 25%
- Buy 25 for €647.00 each and save 25%
Key features
| Manufacturer | Mdp |
|---|---|
| Technologies | Stepper |
| Gammes | Gear motors |
| Maximum axial load | 110 N |
| Maximum radial load | 300 N |
| Holding torque | 15 Nm |
| Slip force | 320 N |
| Number of stages | 3 |
Detailed specifications
| Step angle | 0.035 ° |
|---|---|
| Nominal current per phase | 2 A |
| Angular play under load | 1 ° |
| Bearings | ball bearings 2RS |
| Max ambient operating temperature | 140 °C |
| Min ambient operating temperature | -20 °C |
| Reduction gear type | planetary |
Downloads
 2D Plan |
| 3D Plan |
| Product description |
 Curve |
| User Manual |
